Microsemi Corporation APTC60AM83B1G

Part No.:: APTC60AM83B1G

Manufacturer:: Microsemi Corporation

Category:: Transistors - FETs, MOSFETs - Arrays

Package:: SP1

Datasheet:: APTC60AM83B1G.pdf

Description:: MOSFET 3N-CH 600V 36A SP1

Quantity:: RFQ

Payment:

Shipping:

Product details

Packaging:
Tray
Series:
CoolMOS™
ProductStatus:
Obsolete
FETType:
3 N Channel (Phase Leg + Boost Chopper)
FETFeature:
Super Junction
DraintoSourceVoltage(Vdss):
600V
Current-ContinuousDrain(Id)@25°C:
36A
RdsOn(Max)@IdVgs:
83mOhm @ 24.5A, 10V
Vgs(th)(Max)@Id:
5V @ 3mA
GateCharge(Qg)(Max)@Vgs:
250nC @ 10V
InputCapacitance(Ciss)(Max)@Vds:
7200pF @ 25V
Power-Max:
250W
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Chassis Mount
Category:
Transistors - FETs, MOSFETs - Arrays
Datasheet:

APTC60AM83B1G.pdf
