Lite-On Inc. 6N137S

Part No.:: 6N137S

Manufacturer:: Lite-On Inc.

Category:: Optoisolators - Logic Output

Package:: 8-SMD, Gull Wing

Datasheet:: 6N137S.pdf

Description:: OPTOISO 5KV 1CH OPEN COLL 8SMD

Quantity:: RFQ

Payment:

Shipping:

Product details

Packaging:
Tube
Series:
-
ProductStatus:
Active
NumberofChannels:
1
Inputs-Side1/Side2:
1/0
Voltage-Isolation:
5000Vrms
CommonModeTransientImmunity(Min):
10kV/µs
InputType:
DC
OutputType:
Open Collector
Current-Output/Channel:
50 mA
DataRate:
15MBd
PropagationDelaytpLH/tpHL(Max):
75ns, 75ns
Rise/FallTime(Typ):
22ns, 6.9ns
Voltage-Forward(Vf)(Typ):
1.38V
Current-DCForward(If)(Max):
20mA
Voltage-Supply:
7V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
Category:
Optoisolators - Logic Output
Datasheet:

6N137S.pdf
