IXYS IXYX140N120A4

Part No.:: IXYX140N120A4

Manufacturer:: IXYS

Category:: Transistors - IGBTs - Single

Package:: TO-247-3 Variant

Datasheet:: IXYX140N120A4.pdf

Description:: IGBT 140A 1200V PLUS247

Quantity:: RFQ

Payment:

Shipping:

Product details

Packaging:
Tube
Series:
XPT™, GenX4™
ProductStatus:
Active
IGBTType:
PT
Voltage-CollectorEmitterBreakdown(Max):
1200 V
Current-Collector(Ic)(Max):
480 A
Current-CollectorPulsed(Icm):
1200 A
Vce(on)(Max)@VgeIc:
1.7V @ 15V, 140A
Power-Max:
1500 W
SwitchingEnergy:
4.9mJ (on), 12mJ (off)
InputType:
Standard
GateCharge:
420 nC
Td(on/off)@25°C:
52ns/590ns
TestCondition:
600V, 70A, 1.5Ohm, 15V
ReverseRecoveryTime(trr):
47 ns
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Through Hole
Category:
Transistors - IGBTs - Single
Datasheet:

IXYX140N120A4.pdf
