onsemi NCP4545IMNTWG

Part No.:: NCP4545IMNTWG

Manufacturer:: onsemi

Category:: PMIC - Power Distribution Switches, Load Drivers

Package:: 18-QFN (3x3)

Datasheet:: NCP4545IMNTWG.pdf

Description:: IC PWR SWITCH N-CHAN 1:1 18QFN

Quantity:: RFQ

Payment:

Shipping:

Product details

Packaging:
Tape & Reel (TR),Cut Tape (CT)
Series:
ecoSWITCH™
ProductStatus:
Active
SwitchType:
General Purpose
NumberofOutputs:
1
Ratio-Input:Output:
1:1
OutputConfiguration:
High Side
OutputType:
N-Channel
Interface:
On/Off
Voltage-Load:
3V ~ 5.5V
Voltage-Supply(Vcc/Vdd):
Not Required
Current-Output(Max):
10.5A
RdsOn(Typ):
4.9mOhm
InputType:
Non-Inverting
Features:
Slew Rate Controlled
FaultProtection:
-
OperatingTemperature:
0°C ~ 70°C (TA)
MountingType:
Surface Mount
Category:
PMIC - Power Distribution Switches, Load Drivers
Datasheet:

NCP4545IMNTWG.pdf
