Nisshinbo Micro Devices Inc. R1240N001B-TR-FE

Part No.:: R1240N001B-TR-FE

Manufacturer:: Nisshinbo Micro Devices Inc.

Category:: PMIC - Voltage Regulators - DC DC Switching Controllers

Package:: SOT-23-6

Datasheet:: R1240N001B-TR-FE.pdf

Description:: PWM STEP-DOWN DCDC CONVERTER

Quantity:: RFQ

Payment:

Shipping:

Product details

Package/Case:
SOT-23-6
Packaging:
Tape & Reel (TR),Cut Tape (CT)
Series:
-
ProductStatus:
Active
OutputType:
PWM
Function:
Step-Down
OutputConfiguration:
Positive
Topology:
Buck
NumberofOutputs:
1
OutputPhases:
1
Voltage-Supply(Vcc/Vdd):
4.5V ~ 30V
Frequency-Switching:
1.25MHz
DutyCycle(Max):
85%
SynchronousRectifier:
No
ClockSync:
No
SerialInterfaces:
-
ControlFeatures:
Enable
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
Category:
PMIC - Voltage Regulators - DC DC Switching Controllers
Datasheet:

R1240N001B-TR-FE.pdf
