TE Connectivity Laird VFP69383B22JN-518J

Part No.:: VFP69383B22JN-518J

Manufacturer:: TE Connectivity Laird

Category:: RF Antennas

Package:

Datasheet:: VFP69383B22JN-518J.pdf

Description:: RF ANT SHARKFIN 5 PORT SMA

Quantity:: RFQ

Payment:

Shipping:

Product details

Packaging:
Bulk
Series:
CBRS
ProductStatus:
Active
RFFamily/Standard:
Cellular, General ISM, Navigation, WiFi
FrequencyGroup:
Wide Band
Frequency(Center/Band):
752MHz, 859MHz, 920MHz, 1.561GHz, 1.575GHz, 1.6015GHz, 2.745GHz, 2.45GHz, 5.45GHz
FrequencyRange:
698MHz ~ 806MHz, 824MHz ~ 894MHz, 880MHz ~ 960MHz, 1.559GHz ~ 1.563GHz, 1.574GHz ~ 1.576GHz, 1.598GHz ~ 1.605GHz, 1.69GHz ~ 3.8GHz, 2.4GHz ~ 2.5GHz, 4.9GHz ~ 6GHz
AntennaType:
Module
NumberofBands:
9
VSWR:
2
ReturnLoss:
-
Gain:
0.4dBi, 0.8dBi, 1.2dBi, 2dBi, 2dBi, 2dBi, 4dBi, 2.6dBi, 6.6dBi
Power-Max:
10 W
Features:
Cable - 5.18m, LNA
Termination:
SMA Male
IngressProtection:
IP67
MountingType:
Panel Mount
Height(Max):
1.890 (48.00mm)
Category:
RF Antennas
Datasheet:

VFP69383B22JN-518J.pdf
