PulseLarsen Antennas W3796

Part No.:: W3796

Manufacturer:: PulseLarsen Antennas

Category:: RF Antennas

Package:

Datasheet:: W3796.pdf

Description:: RF ANT 829MHZ/1.575GHZ FLAT BAR

Quantity:: RFQ

Payment:

Shipping:

Product details

Packaging:
Tape & Reel (TR),Cut Tape (CT)
Series:
Domino
ProductStatus:
Active
RFFamily/Standard:
Cellular, Navigation
FrequencyGroup:
Wide Band
Frequency(Center/Band):
829MHz, 1.575GHz, 1.9GHz, 2.5GHz
FrequencyRange:
698MHz ~ 960MHz, 1.43GHz ~ 1.66GHz, 1.69GHz ~ 2.2GHz, 2.3GHz ~ 2.7GHz
AntennaType:
Flat Bar
NumberofBands:
4
VSWR:
3
ReturnLoss:
-6dB
Gain:
1.5dBi, 2dBi, 5.5dBi, 5dBi
Power-Max:
5 W
Features:
-
Termination:
Solder
IngressProtection:
-
MountingType:
Surface Mount
Height(Max):
0.118 (3.00mm)
Category:
RF Antennas
Datasheet:

W3796.pdf
